Use solvent

• Hydrocarbon solvents (carbonized hydrogen), modified alcohols, or other non-aqueous organic solvents.

Cleaning

• Process A：vacuum ultrasonic cleaning→atmospheric pressure dip→Steam shower→
  ​Vacuum drying

• Process B：Tmodified hydrocarbon→modified hydrocarbon ultrasonic→vacuum
  ultrasonic cleaning→atmospheric pressure dip→Steam shower→Vacuum drying

• ※Process A：Clean lipophilic dirt。 Process B：cleaning hydrophilic and lipophilic dirt.

Cycle time

• 6~10min/ basket( Different washing weight, different output time)

Loss of lotion

• ＜100ml/basket

• >180L/hr (based on hydrocarbon solvents

• Manual cart/automatic conveying (optional)

Loading capability

• 30~100kg

Rotating mechanism

• No rotation / rotation / rotation + shaking (optional)

Equipment Specifications

• Customized cleaning equipment.

• Any hydrophilic or lipophilic processing oil can be cleaned.

• Automatic transmission mechanism, suitable for large-scale production operations.

• Air emissions are much lower than VOC standards, in line with ROHS or any other
  environmental protection regulations.

• Large recovery volume of lotion (≧200L/hr), which makes it easier to maintain the
  cleanliness of lotion.

• The rotating and shaking mechanism of square basket or drum can be used at the same time, which can meet any requirement of workpiece cleaning.

• Steam cleaning greatly improves the cleanliness of the workpiece, which can meet any severe precision cleaning.

• 100% dry workpiece after vacuum drying.

• No oxidation occurs after cleaning.

• No environmental issues such as waste water and air pollution discharge.
